HAWA VARIOFOLD

HAWA Variofold

HAWA Variofold

Variofold -

  • Min. panel width 400 mm

  • Max. panel width 900 mm

  • Max. panel height 2600 mm

  • Max. panel weight 80 kg (176 lbs.)

  • The same components may be used for constructing installations that open to the left or right, inwards or outwards

  • The opposite side may be equipped with a separate pivot door

  • Vertical adjustment ± 3 mm

  • Elegant design

  • Secure locking mechanism

  • Extremely smooth and silent operation

  • Minimal space requirement in stacking area

  • Fully tempered monolithic glass: 10/12/12.7 mm

  • Fully tempered laminated glass: 10,8–13 mm





HAWA PURO & PUROLINO

hjfkh



HAWA APERTO

  • Maximum panel weight 40 kg (88 lbs.)

  • Panel thickness 19 - 25 mm

  • Maximum panel height 2600 mm

  • Panel width 400 - 900 mm

  • Continuous height adjustment +/- 2 mm

  • Minimum axis radius 2000 mm for curved applications

  • Centre stop with adjustable friction

  • Flush-mounted panels

  • Stacking area accommodates up to 7 door panels
