SHUT THE FRONT DOOR! There’s a concealed hinge with an integrated automatic closer?
YES, and it’s the BaSys PIVOTA® Close.
Recently we gave you a quick introduction to BaSys, a german manufacturer who offers a complete line of 3-D adjustable concealed hinges. Now, it’s time to introduce to you to one of their most unique hinges, the PIVOTA® Close.
The BaSys Close is a long sought-after solution to a problem that millworkers and builders have been experiencing since the genesis of concealed hinges. On a project with concealed hinges throughout, you might have a door or two that needs a closer. With our other favorite 3-D adjustable concealed hinge brand, Tectus, this problem required going elsewhere for a solution.
Tectus can of course be paired with the Perko automatic closer by Samuel Heath. BUT, when combining Tectus and Perko, you lose the reason why you selected Tectus in the first place: you lose 3-D adjustability. The Tectus and Perko combo also requires an entirely separate mortise in the door and frame to allow for the Perko, which is less than ideal for millworkers and installers. Plus, it looks quite different and the finish is sometimes difficult to match.
The other option is a concealed overhead closer like the Dorma ITS96, which happens to degrade the capacity of the TECTUS hinge by 30-percent.
The Mechanics of BaSys PIVOTA® Close
Basic stats :
Minimum door thickness: 1-3/4"
Height: 7.08" [180mm]
Width: Frame-Door 1.18" [30mm]
3D adjustment (sideways ± 3,0 mm, up-down +mm 2,0 mm, in-out)
Maintenance-Free Bearings
For doors up to 110 lbs (50 kg) with one Close + one DX 61 3D installed
For doors up to 176 lbs (80 kg) with 2 hinges installed
The Beauty of BaSys PIVOTA® Close
One reason why we really like BaSys PIVOTA® is that they feature magnetically fixed cover plates for optics free-of-screws. We know that specifiers of concealed hinges like clean, seamless design, which is why we carry the BaSys PIVOTA® “Design” models that have no visible screws.
BaSys also has a wide range of beautiful finishes.
Other plated finishes are available and BaSys PIVOTA® hinges can also be custom finished (e.g. 24k gold plating, hot pink powder-coated). For custom RAL colors or finishes, please contact us for pricing and minimum quantities.
The Award-Winning BaSys PIVOTA® Close
BaSys hinges are brand new to the US market, but already a tried and true player in Europe. And we aren’t the only ones shouting on the rooftops about BaSys Close. In fact, the BaSys PIVOTA® DXS Close is the winner of two prestigious German design awards: the 2017 Innovationspreis Architektur + Bauwesen and the 2018 Iconic Award from the German Design Council.
